Android SDK - Low Level APIs

The following low level APIs are provided in the Android sdk:

PCast - Use the Phenix platform to Publish and Subscribe to streams
Room - Use the Phenix platform to broadcast changes between all of your users
Chat - Use the Phenix platform to send and receive chat messages between users

Android SDK

Initializing

Before using a PCast object, it is required to be initialized as shown.

import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.PCastInitializeOptions;
import com.phenixrts.pcast.android.AndroidPCastFactory;

PCast pcast = AndroidPCastFactory.createPCast(this);

// #1 Default initialization options
pcast.initialize();

// OR

// #2 Custom initialization options (initialized by constructor)
final boolean enableProcessTerminationSignalHandling = false;
PCastInitializeOptions initOptions = new PCastInitializeOptions(
    enableProcessTerminationSignalHandling);

pcast.initialize(initOptions);

Initialize Options

Name	Description
enableProcessTerminationSignalHandling	Controls if process termination signal handling is enabled or not
configureLogging	Control if phenix logging is enabled
streamingSourceMapping	Allows partial override of streaming source URIs

Stream Source Mapping

Optional field that can be provided with PCastInitializeOptions. It only has an effect on the subscriber side, and only for streams with the “streaming” capability (on both publisher and subscriber side). The property allows you to redirect requests from the SDKs player to your own CDN.

import com.phenixrts.pcast.PCastInitializeOptions;
import com.phenixrts.pcast.StreamingSourceMapping;

final String patternToReplace = "https:\\/\\/phenixrts\\.com\\/video";
final String replacement = "https://myown.cdn.com";
final StreamingSourceMapping streamingSourceMapping = new StreamingSourceMapping(
    patternToReplace, replacement);

final boolean enableProcessTerminationSignalHandling = false;
final boolean configureLogging = true;

final PCastInitializeOptions pcastInitOptions = new PCastInitializeOptions(
    enableProcessTerminationSignalHandling,
    configureLogging,
    streamingSourceMapping);

Name	Description
patternToReplace	A regular expression indicating with part of the incoming streaming source URI to replace
replacement	The replacement string to insert into the streaming source URI

Note: The regular expression has to be properly escaped to work correctly.

Connect and Authenticate

Please follow the self explanatory example for connecting and authenticating to PCast.

import android.util.Log;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.RequestStatus;

// Obtained via Admin API
String authenticationToken = ...;
// Previously initialized
PCast pcast = ...;

pcast.start(
    authenticationToken,
    new PCast.AuthenticationCallback() {
        @Override
        public void onEvent(
            PCast pcast,
            RequestStatus requestStatus,
            String sessionId) {
                if (requestStatus == RequestStatus.OK) {
                    Log.i("Phenix SDK Example", "PCast started...");
                } else {
                    Log.e("Phenix SDK Example", "Failed to start PCast...");
                }
        }
    },
    new PCast.OnlineCallback() {
        @Override
        public void onEvent(PCast pcast) {
            Log.i("Phenix SDK Example", "We are online...");
        }
    },
    new PCast.OfflineCallback() {
        @Override
        public void onEvent(PCast pcast) {
            Log.i("Phenix SDK Example", "We are offline...");
        }
    });

Parameters

Name	Type	Description
authenticationToken (required)	string	The authentication token generated using the Admin API
authenticationCallback (required)	PCast.AuthenticationCallback	Called upon successful authentication or when authentication failed or has to be redone. Upon successful authentication, the authenticationCallback will be called with status=RequestStatus.OK. If at any time a new authenticationToken is required, then the authenticationCallback is called with status=RequestStatus.UNAUTHORIZED to indicate that we are no longer authenticated.
onlineCallback (required)	PCast.OnlineCallback	Called when the client is connected to the streaming platform
offlineCallback (required)	PCast.OfflineCallback	Called when the client is disconnected from the streaming platform. Ongoing streams may continue while we are temporarily disconnected. However, no new streams can be started while being disconnected. The client automatically tries to reconnect and will call onlineCallback when it succeeds in doing so or eventually call authenticationCallback to indicate that re-authentication is required.

Authentication Callback Status Codes

Status	Valid Fields	Description
RequestStatus.OK	sessionId	Authentication succeeded, the sessionId is populated
RequestStatus.UNAUTHORIZED	<none>	Authentication failed or re-authentication required
<varies>	<none>	Authentication failed for other reasons

Disconnect

Please follow the self explanatory example for disconnecting from PCast.

import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.RequestStatus;

// Previously initialized and started
PCast pcast = ...;

pcast.stop();

// Once you are done using PCast (e.g. exiting the app)
pcast.shutdown();

Get Local User Media

Please follow the self explanatory example for getting local user media.

import com.phenixrts.pcast.FacingMode;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.UserMediaOptions;
import com.phenixrts.pcast.UserMediaStream;
import com.phenixrts.pcast.android.AndroidPCastFactory;

// Previously initialized and started
PCast pcast = ...;

UserMediaOptions gumOptions = new UserMediaOptions();

// Customize options if desired
gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.FACING_MODE, Arrays.asList(new DeviceConstraint(FacingMode.USER)));
gumOptions.getAudioOptions().enabled = false;

pcast.getUserMedia(
    gumOptions,
    new PCast.UserMediaCallback() {
        @Override
        public void onEvent(
            PCast pcast,
            RequestStatus status,
            UserMediaStream userMediaStream) {
                // Check status and store 'userMediaStream'
        }
    });

Parameters

Name	Type	Description
options (required)	UserMediaOptions	The options defining the requested user media stream
userMediaCallback (required)	PCast.UserMediaCallback	Upon acquiring of the user media stream, the userMediaCallback will be called with status=RequestStatus.OK. If the user media is currently used by another application, then you may receive a code status=RequestStatus.CONFLICT . If the operation fails with status=RequestStatus.FAILED then please check the logs for more information

Device Capability

Name	Description
DeviceCapability.WIDTH	Width in pixels
DeviceCapability.HEIGHT	Height in pixels
DeviceCapability.FRAME_RATE	Number of frames per second
DeviceCapability.FACING_MODE	Facing mode
DeviceCapability.FLASH_MODE	Flash mode
DeviceCapability.DEVICE_ID	Device ID string (obtain from here)
DeviceCapability.LOCATION	Device Location
DeviceCapability.POLAR_PATTERN	Polar pattern
DeviceCapability.AUDIO_ECHO_CANCELATION_MODE	Audio echo cancelation mode

Constraint Type

Name	Description
ConstraintType.MIN	Hard constraint: Capability must have at least the specified value
ConstraintType.MAX	Hard constraint: Capability must have at most the specified value
ConstraintType.EXACT	Hard constraint: Capability must have exactly the specified value
ConstraintType.IDEAL	Soft constraint: Capability should have specified value, but other values are acceptable (default)

Facing Mode

Name	Description
FacingMode.AUTOMATIC	Select a facing mode automatically (default)
FacingMode.ENVIRONMENT	Facing the surrounding environment (e.g., back camera)
FacingMode.USER	Facing the user (e.g., front camera)

Flash Mode

Only applicable to video devices

Name	Description
FlashMode.AUTOMATIC	Flash is turned on automatically when needed (default)
FlashMode.ALWAYS_ON	Flash is on (if available)
FlashMode.ALWAYS_OFF	Flash is off

Device Location

Name	Description
Location.AUTOMATIC	Select any device (default)
Location.UPPER	Mounted on top of phone/tablet
Location.LOWER	Mounted at bottom of phone/tablet

Polar Pattern

Only applicable to audio devices

Name	Description
PolarPattern.AUTOMATIC	Automatically select pattern (default)
PolarPattern.OMNIDIRECTIONAL	Equally sensitive to sound from any direction
PolarPattern.CARDIOID	Most sensitive to sound from the direction in which the data source points and is (nearly) insensitive to sound from the opposite direction
PolarPattern.SUBCARDIOID	Most sensitive to sound from the direction in which the data source points and is less sensitive to sound from the opposite direction

Note: This option is currently not supported on Android

Audio Echo Cancelation Mode

Only applicable to audio devices

Name	Description
AudioEchoCancelationMode.AUTOMATIC	Automatically select AEC mode (default)
AudioEchoCancelationMode.ON	Enable AEC if available
AudioEchoCancelationMode.OFF	Disable AEC

Note (as of v2019.2.0): Automatic mode is currently always set to “off” on Android.

Note 2 (as of v2019.2.0): AudioEchoCancelationMode must be set to ON in the UserMediaOptions for all published streams and RendererOptions for all subscribed streams in order for AEC to work reliably on all Android devices.

Updating Options

Sometimes you find it useful to change the camera while a stream is running or just would like to turn on the flash light temporarily.

import com.phenixrts.pcast.UserMediaOptions;
import com.phenixrts.pcast.UserMediaStream;

// Previously obtained via 'getUserMedia'
UserMediaStream userMediaStream = ...;

// Previously initialized and used with 'getUserMedia'
UserMediaOptions gumOptions = new UserMediaOptions();

gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.FACING_MODE, Arrays.asList(new DeviceConstraint(FacingMode.ENVIRONMENT)));
gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.FLASH_MODE, Arrays.asList(new DeviceConstraint(FlashMode.ALWAYS_ON)));
gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.HEIGHT,
    Arrays.asList(new DeviceConstraint(720, ConstraintType.EXACT)));
gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.WIDTH,
    Arrays.asList(
        new DeviceConstraint(800, ConstraintType.MIN),
        new DeviceConstraint(1500, ConstraintType.MAX)));

userMediaStream.applyOptions(gumOptions);

Enumerating Source Devices

You can get a list of available source devices.

import android.util.Log;
import com.phenixrts.pcast.MediaType;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.SourceDeviceInfo;

// Previously initialized and started
PCast pcast = ...;

pcast.enumerateSourceDevices(
    MediaType.VIDEO,
    new PCast.EnumerateSourceDevicesCallback() {
        @Override
        public void onEvent(PCast pcast, SourceDeviceInfo[] devices) {
            // Store devices as needed
        }
    });

Parameters

Name	Type	Description
mediaType (required)	MediaType	The media type for which to enumerate source devices

SourceDeviceInfo fields

Name	Type	Description
id	String	Source device ID
name	String	Source device Name
mediaType	MediaType	Source device media type
deviceType	SourceDeviceType	Source device type
facingMode	FacingMode	Source device facing mode

Media Type

Name	Description
MediaType.VIDEO	Video
MediaType.AUDIO	Audio

Source Device Type

Name	Description
SourceDeviceType.NULL	Null device (e.g. blank screen or silence)
SourceDeviceType.PHYSICAL	Physical device (e.g. camera or microphone)
SourceDeviceType.SYSTEM_OUTPUT	System output capture (screencast)

Screencasting `android 5.0 or later`

You can also stream the screen of your phone.

In order to do this, you must first enumerate the available source devices to find the screencast device ID.

Find the screencast device ID

import android.util.Log;
import com.phenixrts.pcast.MediaType;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.SourceDeviceInfo;
import com.phenixrts.pcast.SourceDeviceType;

// Previously initialized and started
PCast pcast = ...;

pcast.enumerateSourceDevices(
    MediaType.VIDEO,
    new PCast.EnumerateSourceDevicesCallback() {
        @Override
        public void onEvent(PCast pcast, SourceDeviceInfo[] devices) {
            for (SourceDeviceInfo info : devices) {
                if (info.sourceDeviceType == SourceDeviceType.SYSTEM_OUTPUT) {
                    Log.i("Phenix SDK Example", "Screencasting is available");
                    String screenCaptureDeviceId = info.id;
                    // Store screenCaptureDeviceId
                }
            }
        }
    });

pcast.enumerateSourceDevices();

The screen capture device requires a valid android.media.projection.MediaProjection object to be passed to the SDK before it can be used. The MediaProjection must stay valid for the duration of the screencast.

Next, pass a valid android.media.projection.MediaProjection object

import android.media.projection.MediaProjection;
import com.phenixrts.pcast.android.AndroidPCastFactory;

// Previously obtained by calling
// android.media.projection.MediaProjectionManager.getMediaProjection(),
// see Android API reference.
MediaProjection mediaProjection = ...;

AndroidPCastFactory.setMediaProjection(mediaProjection);

Finally, pass the screen capture device ID

Next, pass the screen capture device ID to getUserMedia() in the user media options.

import com.phenixrts.pcast.FacingMode;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.UserMediaOptions;
import com.phenixrts.pcast.UserMediaStream;

// Previously initialized and started
PCast pcast = ...;

// Found by calling enumerateSourceDevices() as described above
String screenCaptureDeviceId = ...;

UserMediaOptions gumOptions = new UserMediaOptions();

gumOptions.getVideoOptions().capabilityConstraints.put(
    DeviceCapability.DEVICE_ID, Arrays.asList(new DeviceConstraint(screenCaptureDeviceId)));

pcast.getUserMedia(
    gumOptions,
    new PCast.UserMediaCallback() {
        @Override
        public void onEvent(
            PCast pcast,
            RequestStatus status,
            UserMediaStream userMediaStream) {
                // Check status and store 'userMediaStream'
        }
    });

Please follow the self explanatory code snippets for understanding above steps.

Publish a Stream

import android.util.Log;
import com.phenixrts.pcast.MediaStream;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.Publisher;
import com.phenixrts.pcast.RequestStatus;
import com.phenixrts.pcast.StreamEndedReason;
import com.phenixrts.pcast.UserMediaOptions;
import com.phenixrts.pcast.UserMediaStream;

// Previously initialized and started
PCast pcast = ...;
// Previously obtained via Admin API
String streamToken = ...;
// Previously obtained via either PCast.subscribe()
// or UserMediaStream.getMediaStream()
MediaStream mediaStream = ...;

String[] tags = { "my-tag" };

pcast.publish(
    streamToken,
    mediaStream,
    new PCast.PublishCallback() {
        @Override
        public void onEvent(
            PCast pcast,
            RequestStatus requestStatus,
            Publisher publisher) {
                // Check status and store 'publisher'

                // The "streamId" of the publisher
                String streamId = publisher.getStreamId();

                if (publisher.hasEnded()) {
                    // Checks if the publisher has ended
                }

                // Attach publisher ended callback
                publisher.setPublisherEndedCallback(
                    new Publisher.PublisherEndedCallback() {
                        @Override
                        public void onEvent(
                            Publisher publisher,
                            StreamEndedReason reason,
                            String reasonDescription) {
                                // Called when the stream has ended
                                Log.i("Phenix SDK Example",
                                    "Publish stream ended with reason ["
                                    + reasonDescription + "]");
                        }
                    });

                // To stop later
                publisher.stop("I-am-done-publishing");
        }
    },
    tags);

Parameters

Name	Type	Description
streamToken (required)	String	The publish token is generated using the Admin API
mediaStream (required)	MediaStream	The user media stream acquired through PCast.subscribe(…) or locally with UserMediaStream.getMediaStream()
publishCallback (required)	PCast.PublishCallback	Called upon completion of the operation
tags (optional)	String[]	Tags that will be provided with the stream notifications to your backend callback endpoint

StreamEndedReason

Reason	Description
StreamEndedReason.ENDED	The stream ended normally
StreamEndedReason.FAILED	The stream failed
StreamEndedReason.CENSORED	The stream was censored
StreamEndedReason.MAINTENANCE	A maintenance event caused this stream to be terminated
StreamEndedReason.CAPACITY	The stream was terminated due to capacity limitations
StreamEndedReason.APP_BACKGROUND	The stream was terminated due to the mobile app entering into the background
StreamEndedReason.CUSTOM	A custom termination reason is provided in the “reasonDescription” field

Process Raw Frames

The frame-ready API allows for pre-processing of raw audio and video frames before they are encoded and transmitted.

Any processing needs to keep up with the incoming frame rate; otherwise some of the incoming frames will be dropped to compensate.

import android.graphics.Bitmap;
import com.phenixrts.media.audio.android.AndroidAudioFrame;
import com.phenixrts.media.video.android.AndroidVideoFrame;
import com.phenixrts.pcast.FrameNotification;
import com.phenixrts.pcast.MediaStreamTrack;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.UserMediaStream;
import com.phenixrts.pcast.android.AndroidReadAudioFrameCallback;
import com.phenixrts.pcast.android.AndroidReadVideoFrameCallback;

// Previously obtained via PCast.getUserMedia
final UserMediaStream userMediaStream = ...;

final MediaStreamTrack[] videoTracks = userMediaStream.getMediaStream().getVideoTracks();

for (MediaStreamTrack videoTrack : videoTracks) {
  userMediaStream.setFrameReadyCallback(videoTrack,
      (frameNotification) -> {
        frameNotification.read(new AndroidReadVideoFrameCallback() {
          @Override
          public void onVideoFrameEvent(AndroidVideoFrame videoFrame) {
            final Bitmap pixelBuffer = videoFrame.bitmap;
            final int displayHeightInPixels = pixelBuffer.getHeight();
            final int displayWidthInPixels = pixelBuffer.getWidth();

            // Manipulate bitmap as needed
            ...

            frameNotification.write(videoFrame);
          }
        });
      });
}

final MediaStreamTrack[] audioTracks = userMediaStream.getMediaStream().getAudioTracks();

for (MediaStreamTrack audioTrack : audioTracks) {
  userMediaStream.setFrameReadyCallback(audioTrack,
      (frameNotification) -> {
        frameNotification.read(new AndroidReadAudioFrameCallback() {
          @Override
          public void onAudioFrameEvent(AndroidAudioFrame audioFrame) {
            // Attenuate audio:
            for (int sampleIndex = 0; sampleIndex < audioFrame.audioSamples.length; ++sampleIndex) {
              audioFrame.audioSamples[sampleIndex] *= 0.1;
            }

            frameNotification.write(audioFrame);
          }
        });
      });
}

Frame Notification API

Name	Argument	Description
read	FrameReadyForProcessingCallback	Retrieves current raw frame in form of an AndroidAudioFrame or AndroidVideoFrame
write	AndroidAudioFrame/AndroidVideoFrame	Writes back a processed or newly generated frame. The frame can have a different resolution and timestamps
drop	(none)	Instructs stream to drop the current frame

AndroidAudioFrame

Name	Type	Description
sampleRateInHz	int	Audio sampling frequency, e.g. 48000
numberOfChannels	int	Number of channels, e.g. 1 for mono, 2 for stereo
timestampInMicroseconds	long	Timestamp of current audio frame in us
audioSamples	short[]	Audio samples; if more than one channel is present, then samples will be interleaved

AndroidVideoFrame

Name	Type	Description
bitmap	android.graphics.Bitmap	Bitmap containing the pixel data. This object also contains other properties such as width and height.
timestampInMicroseconds	long	Timestamp of current video frame in us
durationInMicroseconds	long	Duration of the current video frame in us

Limit Bitrate

The published video bitrate can be limited temporarily if needed. The returned disposable allows you to control for how long the limitation should stay in effect. If limitBandwidth is called multiple times before any of the previous disposables are released, then only the most recent override will remain in effect until its disposable is released. Relasing any of the disposables from earlier limitBandwidth calls will have no effect.

To release a Disposable deterministrically, call dispose on it.

import com.phenixrts.common.Disposable;
import com.phenixrts.pcast.Publisher;

// Previously obtained
Publisher publisher = ...;

Disposable disposable = publisher.limitBandwidth(200000);

// ... after some time: force dispose to cancel bandwidth limitation:
disposable.dispose();

Parameters

Name	Type	Description
bandwidthLimitInBps (required)	long	Maximum bitrate limit in bps for video

import android.util.Log;
import com.phenixrts.pcast.MediaStream;
import com.phenixrts.pcast.PCast;
import com.phenixrts.pcast.RequestStatus;
import com.phenixrts.pcast.StreamEndedReason;

// Previously initialized and started
PCast pcast = ...;
// Previously obtained via Admin API
String streamToken = ...;

pcast.subscribe(
    streamToken,
    new PCast.SubscribeCallback() {
        @Override
        public void onEvent(
            PCast pcast,
            RequestStatus requestStatus,
            MediaStream mediaStream) {
                // Check status and store 'mediaStream'

                // Attach stream ended callback
                mediaStream.setStreamEndedCallback(
                    new MediaStream.StreamEndedCallback() {
                        @Override
                        public void onEvent(
                            MediaStream mediaStream,
                            StreamEndedReason reason,
                            String reasonDescription) {
                                Log.i("Phenix SDK Example",
                                    "Subscriber stream ended with reason ["
                                    + reasonDescription + "]");
                        }
                    }
                });

                // To stop later
                mediaStream.stop();
        }
    });

Parameters

Name	Type	Description
streamToken (required)	String	The publish token is generated using the Admin API
subscribeCallback (required)	PCast.SubsribeCallback	Called upon completion of the operation

View a Stream

In order to view a stream you have to supply a Surface for the Renderer to draw on.

import com.phenixrts.pcast.MediaStream;
import com.phenixrts.pcast.Renderer;
import com.phenixrts.pcast.RendererStartStatus;
import com.phenixrts.pcast.android.AndroidVideoRenderSurface;

// Previously obtained via either PCast.subscribe
// or PhenixUserMediaStream.mediaStream
MediaStream mediaStream = ...;

// Previously obtained, e.g., from a SurfaceView
Surface renderSurface = ...;

Renderer renderer = mediaStream.createRenderer();

RendererStartStatus status =
    renderer.start(new AndroidVideoRenderSurface(renderSurface));

if (status == RendererStartStatus.OK) {
    Log.i("Phenix SDK Example", "Renderer started successfully");
} else {
    Log.e("Phenix SDK Example", "Renderer start failed");
}

// To stop later
renderer.stop();

Renderer options

It is possible to pass additional options when creating a renderer.

import com.phenixrts.pcast.AspectRatioMode;
import com.phenixrts.pcast.MediaStream;
import com.phenixrts.pcast.Renderer;
import com.phenixrts.pcast.RendererOptions;

// Previously obtained via either PCast.subscribe or UserMediaStream.mediaStream
MediaStream mediaStream = ...;

RendererOptions options = new RendererOptions();
options.aspectRatioMode = AspectRatioMode.FILL;

Renderer renderer = mediaStream.createRenderer(options);

Properties

Name	Type	Description
aspectRatioMode (optional)	AspectRatioMode	How to fill available video render surface
audioEchoCancelationMode (optional)	AudioEchoCancelationMode	Audio echo cancelation mode
hardwareAcceleratedDecodingMode (optional)	HardwareAcceleratedDecodingMode	Hardware accelerated decoding mode

Aspect Ratio Mode

Name	Description
AspectRatioMode.AUTOMATIC	Defaults to fill
AspectRatioMode.FILL	Fill entire render area. Video may be truncated
AspectRatioMode.LETTERBOX	Black bars are added on sides or top/bottom of render area, video will not be truncated

Note: This option is currently only supported for Real-Time streams

Hardware Accelerated Decoding Mode

Name	Description
HardwareAcceleratedDecodingMode.AUTOMATIC	Use hardware decoding on certified devices
HardwareAcceleratedDecodingMode.ON	Always use hardware decoding
HardwareAcceleratedDecodingMode.OFF	Always use software decoding

Preview Local User Media

import com.phenixrts.pcast.Renderer;
import com.phenixrts.pcast.UserMediaStream;

// Previously obtained via 'getUserMedia'
UserMediaStream userMediaStream = ...;

Renderer renderer = userMediaStream.getMediaStream().createRenderer();

Muting and Unmuting of Audio

import com.phenixrts.pcast.Renderer;

// Previously obtained from media stream
Renderer renderer = ...;

boolean isMuted = renderer.isAudioMuted();
renderer.muteAudio();
renderer.unmuteAudio();

Taking a Screenshot

If you would like to show a preview, you can take a still image from a renderer.

import com.phenixrts.pcast.Renderer;
import com.phenixrts.android.AndroidLastFrameRenderedCallback;

// Previously obtained from media stream and started
Renderer renderer = ...;

renderer.setLastVideoFrameRenderedReceivedCallback(
    new AndroidLastFrameRenderedCallback() {
        @override
        public void onEvent(Renderer renderer, Bitmap videoFrame) {
            // Process the frame as needed
        }
    });

renderer.requestLastVideoFrameRendered();

You can also take a still image from a local stream.

import com.phenixrts.pcast.UserMediaStream;
import com.phenixrts.android.AndroidLastFrameCapturedCallback;

// Previously obtained via 'getUserMedia'
UserMediaStream userMediaStream = ...;

userMediaStream.setLastVideoFrameCapturedReceivedCallback(
    new AndroidLastFrameCapturedCallback() {
        @override
        public void onEvent(Renderer renderer, Bitmap videoFrame) {
            // Process the frame as needed
        }
    });

userMediaStream.requestLastVideoFrameCaptured();

Data Quality Feedback

If you like to show the user feedback about how their internet connectivity affects the stream quality, you can listen for data quality notifications.

import com.phenixrts.pcast.DataQualityReason;
import com.phenixrts.pcast.DataQualityStatus;
import com.phenixrts.pcast.Publisher;
import com.phenixrts.pcast.Renderer;

// Previously obtained from media stream and started
Renderer renderer = ...;

renderer.setDataQualityChangedCallback(
    new Renderer.DataQualityChangedCallback() {
        @Override
        public void onEvent(
            Renderer renderer,
            DataQualityStatus quality,
            DataQualityReason reason) {
                // Inform user, take action based on status and reason
        }
    });

// Previously obtained via PCast.publish
Publisher publisher = ...;

publisher.setDataQualityChangedCallback(
    new Publisher.DataQualityChangedCallback() {
        @Override
        public void onEvent(
            Publisher publisher,
            DataQualityStatus quality,
            DataQualityReason reason) {
                // Inform user, take action based on status and reason
        }
    });

Data Quality Status for Publishers

Status	Reason	Description
DataQualityStatus.NO_DATA	DataQualityReason.NONE	The publisher has a bad internet connection and no data is being streamed.
DataQualityStatus.NO_DATA	DataQualityReason.UPLOAD_LIMITED	The publisher has a bad internet connection and no data is being streamed.
DataQualityStatus.ALL	DataQualityReason.NONE	Good internet connection and no quality reduction in effect.
DataQualityStatus.ALL	DataQualityReason.UPLOAD_LIMITED	The publisher has a slow internet connection and the quality of the stream is reduced.
DataQualityStatus.ALL	DataQualityReason.NETWORK_LIMITED	Subscribers have bad internet connections and the quality of the stream is reduced.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.UPLOAD_LIMITED	The publisher has a bad internet connection and only audio is streamed.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.NETWORK_LIMITED	Subscribers have bad internet connections and only audio is streamed.

Data Quality Status for Viewers

Status	Reason	Description
DataQualityStatus.NO_DATA	DataQualityReason.NONE	The subscriber has a bad internet connection and no data is being received.
DataQualityStatus.NO_DATA	DataQualityReason.DOWNLOAD_LIMITED	The subscriber has a bad internet connection and no data is being received.
DataQualityStatus.NO_DATA	DataQualityReason.PUBLISHER_LIMITED	The publisher has a bad internet connection and no data is being received.
DataQualityStatus.NO_DATA	DataQualityReason.NETWORK_LIMITED	The network is limiting the quality of the stream and no data is being received.
DataQualityStatus.ALL	DataQualityReason.NONE	Good internet connection and no quality reduction in effect.
DataQualityStatus.ALL	DataQualityReason.DOWNLOAD_LIMITED	The subscriber has a bad internet connection and the quality of the stream is reduced.
DataQualityStatus.ALL	DataQualityReason.PUBLISHER_LIMITED	The publisher has a bad internet connection and the quality of the stream is reduced.
DataQualityStatus.ALL	DataQualityReason.NETWORK_LIMITED	Other subscribers have bad internet connections and the quality of the stream is reduced.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.NONE	Audio only stream, good internet connection and no quality reduction in effect.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.DOWNLOAD_LIMITED	The subscriber has a bad internet connection and is only receiving audio.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.PUBLISHER_LIMITED	The publisher has a bad internet connection and the subscriber is only receiving audio.
DataQualityStatus.AUDIO_ONLY	DataQualityReason.NETWORK_LIMITED	The network is limiting the quality of the stream and the subscriber is only receiving audio.

Handling Dimension Changes

Cameras may be switched at runtime and devices may be rotated. Register a handler to receive a notification whenever the video dimension changes.

import com.phenixrts.pcast.Dimensions;
import com.phenixrts.pcast.Renderer;

// Previously obtained from media stream
Renderer renderer = ...;

renderer.setVideoDisplayDimensionsChangedCallback(
    new Renderer.VideoDisplayDimensionsChangedCallback() {
        @Override
        public void onEvent(
            Renderer renderer,
            Dimensions displayDimensions) {
                // Can get called multiple times while rendering a stream
                // Values in displayDimensions.width, displayDimensions.height
        }
    });

Room Service

Set up a room and manage members, streams, and chat. Some typical uses for rooms include:

Broadcast video chats between multiple people - few to many
Large-scale video chat
Conference calls with integrated video chat
Real-time web channels for hosting media content. See View a Channel with the Express API
Town hall meetings

To get started, create a room of the type associated with your need.

Initializing

First you will need to initialize a room service object. This object is used for creating, joining, and leaving a room. As well, use this object for managing the room you enter (active room), members, and the model of your Self.

Note: PCast must be initialized and started when invoking createRoomService so that a valud session ID is present.

import android.content.Context;

import com.phenixrts.environment.android.AndroidContext;
import com.phenixrts.pcast.PCast;
import com.phenixrts.room.RoomService;
import com.phenixrts.room.RoomServiceFactory;

// IMPORTANT: Before accessing any of the static factories, make sure the context is passed to Phenix:
final Context context = ...;  // e.g. Activity.getApplication();
AndroidContext.setContext(context);

final PCast pcast = ...;  // previously obtained
final RoomService roomService = RoomServiceFactory.createRoomService(pcast);

Parameters

Name	Type	Description
pcast (required)	PCast	Instantiated PCast object. Must already be authenticated

RoomService

Name	Signature	Returns	Description
getRoomInfo	(roomId, alias, callback)	Room	See Get Room Info
createRoom	(room, callback)	Room	See Create a Room
joinRoom	(roomId, alias, callback)	Room	See Join a Room
leaveRoom	(callback)	void	See Leave a Room
destroyRoom	(callback)	void	See Destroy a Room
getSelf	()	Observable of Member)	Observable of self member
getObservableActiveRoom	()	Observable of Room)	Observable of the active room

Instantiate Self Member Model

Before entering a room the RoomService must have a valid model of the Self member. The Self member model may be updated at any time by changing observable values and calling commitChanges. See Update Self Model.

Update Self Model

Broadcast local changes of the Self model to all the members in the room. These changes are sent to our server which forwards the changes to all members in the room. This works whether or not you are currently in a room.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Member;
import com.phenixrts.room.MemberRole;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained
final Member selfMember = roomService.getSelf();

selfMember.getObservableScreenName().setValue("My New Screen Name");
selfMember.getObservableRole().setValue(MemberRole.AUDIENCE);

// Commit changes to self if already in a room
selfMember.commitChanges((RequestStatus status, String message) -> {
  if (status == RequestStatus.OK) {
    // Successfully updated self
  } else {
    // Handle error
  }
});

To undo uncommitted local changes, use reload:

import com.phenixrts.room.Member;
import com.phenixrts.room.MemberRole;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained
final Member selfMember = roomService.getSelf();

selfMember.getObservableScreenName().setValue("My New Screen Name");
selfMember.getObservableRole().setValue(MemberRole.AUDIENCE);

// Decided to undo changes
selfMember.reload();

Update Self Callback Arguments

Name	Type	Description
status	RequestStatus	The status of the operation
message	String	Error message, if applicable

Set Self Streams

The self model must have at least one stream when joining the room as any member role besides Audience.

import com.phenixrts.room.Member;
import com.phenixrts.room.RoomService;
import com.phenixrts.room.Stream;
import com.phenixrts.room.StreamType;
import com.phenixrts.room.TrackState;

final RoomService roomService = ...;  // previously obtained
final Member selfMember = roomService.getSelf();

final Stream selfStream = roomService.createStream(
    "http://myuri.stream", StreamType.USER, TrackState.ENABLED, TrackState.ENABLED);

selfMember.getObservableStreams().setValue(new Stream[] {selfStream});

// Now commit changes

Parameters

Name	Type	Description
uri (required)	String	Unique identifier for stream.
type (required)	StreamType	Type of stream - see Stream Types
audioState (required)	TrackState	State of the audio track - see Stream Track States
videoState (required)	TrackState	State of the video track - see Stream Track States

Get Room Info

Get room info with the provided room details without joining the room.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

// Either provide alias or roomId, other can be null or empty
final String roomId = "us-central#demo#exampleRoomId";
final String alias = null;

roomService.getRoomInfo(roomId, alias, (RoomService roomService, RequestStatus status, Room room) -> {
  if (status == RequestStatus.OK) {
    // Do something with room
  } else {
    // Handle error
  }
});

Parameters

Name	Type	Description
roomId (required)	String	ID of the room
alias (optional)	String	Alternative to roomId - alias of the room
getRoomInfoCallback (required)	RoomService.GetRoomInfoCallback	Callback with the status of the request and the room model

Get Room Info Callback Arguments

Name	Type	Description
roomService	RoomService	The room service making the callback
status	RequestStatus	The status of the operation
room	Room	Immutable room object

Get Room Info Callback Status Codes

Status	Description
ok	Get room info succeeded
not-found	Get room info failed. Room does not exist - verify room data or create the room
<varies>	Get room info failed for other reasons

Create a Room

Create a room with the provided details

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomOptions;
import com.phenixrts.room.RoomService;
import com.phenixrts.room.RoomServiceFactory;
import com.phenixrts.room.RoomType;

final RoomService roomService = ...;  // previously obtained

final String roomName = "My Room Name";
final String description = "Deep thoughts only";

final RoomOptions roomOptions = RoomServiceFactory.createRoomOptionsBuilder()
    .withName(roomName)
    .withDescription(description)
    .withType(RoomType.MULTI_PARTY_CHAT)
    .buildRoomOptions();

roomService.createRoom(
    roomOptions,
    (RoomService service, RequestStatus status, Room room) -> {
      if (status == RequestStatus.OK) {
        // Do something with room
      } else {
        // Handle error
      }
    });

Parameters

Name	Type	Description
options (required)	RoomOptions	Room creation options
callback (required)	RoomService.CreateRoomCallback	Callback with the status of the request and the room model

Create Room Callback Arguments

Name	Type	Description
roomService	RoomService	The room service making the callback
status	RequestStatus	The status of the operation
room	Room	Immutable room object

Create Room Callback Status Codes

Status	Description
ok	Create room succeeded. This can also mean that the room already existed
<varies>	Create room failed for other reasons

RoomOptionsBuilder

Name	Type	Default	Description
withName (required)	String		Name of room
withType (required)	RoomType		Room type
withAlias (optional)	String	<generated>	Room Alias. If not passed in, it will be generated for you
withDescription (optional)	String	<empty>	Room description
buildRoomOptions	<none>		Builds the `RoomOptions`

Join a Room

Join a room with the Self model. After successfully joining a room that room becomes the active room and can be returned via the getObservableActiveRoom method.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

// Either provide alias or roomId, other can be null or empty
final String roomId = null;
final String alias = "exampleRoom";

roomService.joinRoom(roomId, alias, (RoomService roomService, RequestStatus status, Room room) -> {
  if (status == RequestStatus.OK) {
    // Do something with room
  } else {
    // Handle error
  }
});

Parameters

Name	Type	Description
roomId (required)	String	ID of the room
alias (optional)	String	Alternative to roomId - alias of the room
callback (required)	RoomService.JoinRoomCallback	Callback with the status of the request and the room model

Join Room Callback Arguments

Name	Type	Description
roomService	RoomService	The room service making the callback
status	RequestStatus	The status of the operation
room	Room	Immutable room object

Join Room Callback Status Codes

Status	Description
ok	Join room succeeded
not-found	Join room failed. Room does not exist - create room first
<varies>	Join room failed for other reasons

After entering a room you may use the active room to get the observable members and associated metadata. Here we provide an example for accessing each member’s streams whenever the list of members is updated. Remember: Since each observable behaves like a Behavior Rx Subject, your subscriber will always get called back immediately with the current value (in this case the list of members), see Observable.

import com.phenixrts.common.Disposable;
import com.phenixrts.common.Observable;
import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Member;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;
import com.phenixrts.room.Stream;

final RoomService roomService = ...;  // previously obtained

final Observable<Room> observableActiveRoom = roomService.getObservableActiveRoom();

// For this simple example, we assume that there is an active room.
// In a production environment, this can return null if we have not currently joined a room. In that case
// you would want to listen as a subscriber on the 'observableActiveRoom' for updates
final Room activeRoom = observableActiveRoom.getValue();
final Observable<Member[]> observableMembers = activeRoom.getObservableMembers();

final Disposable subscription = observableMembers.subscribe((change) -> {
  final Member[] currentMembers = (Member[])change;
  for (Member member : currentMembers) {
    final Stream[] currentStreams = member.getObservableStreams().getValue();
    // Now do something with this member's streams
  }
});

// The subscription will remain active for as long as 'subscription' is kept alive or not disposed

Update Room Model

Broadcast local changes of the Room model to all the members in the room. These changes are sent to our server which forwards the changes to all members in the room.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

final Room room = roomService.getObservableActiveRoom().getValue();

room.getObservableDescription().setValue("My New Room Description");
room.commitChanges((RequestStatus status, String message) -> {
  if (status == RequestStatus.OK) {
    // Successfully updated room
  } else {
    // Handle error (`message` may provide more information about what went wrong)
  }
});

Parameters

Name	Type	Description
callback (required)	Room.CommitCallback	Callback with the status of the request

Update Room Callback Arguments

Name	Type	Description
status	RequestStatus	The status of the operation
message	String	Error message, if applicable

Update Room Callback Status Codes

Status	Description
ok	Update room succeeded
<varies>	Update room failed for other reasons

Leave a Room

Leave the current active room. Self is not modified.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

roomService.leaveRoom((RoomService roomService, RequestStatus status) -> {
  if (status == RequestStatus.OK) {
    // Successfully left room, no action required
  } else {
    // Handle error
  }
});

Parameters

Name	Type	Description
callback (required)	RoomService.LeaveRoomCallback	Callback with the status of the request

Leave Room Callback Arguments

Name	Type	Description
roomService	RoomService	The room service making the callback
status	RequestStatus	The status of the operation

Update Room Callback Status Codes

Status	Description
ok	Leave room succeeded
<varies>	Leave room failed for other reasons

Destroy a Room

Destroys the current active room assuming your self member has the permissions.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.room.Room;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

roomService.destroyRoom((RoomService roomService, RequestStatus status) -> {
  if (status == RequestStatus.OK) {
    // Successfully destroyed room, no action required
  } else {
    // Handle error
  }
});

Parameters

Name	Type	Description
callback (required)	RoomService.DestroyRoomCallback	Callback with the status of the request

Leave Room Callback Arguments

Name	Type	Description
roomService	RoomService	The room service making the callback
status	RequestStatus	The status of the operation

Update Room Callback Status Codes

Status	Description
ok	Destroy room succeeded
<varies>	Destroy room failed for other reasons

Observe Room size

Subscribe to observable to receive periodic room size updates. The room size corresponds to the total number of members currently in the room, which does include audience members.

This is a so called cold observable, which means that you may not immediately receive an update. It also means that both getValue and setValue methods will cause a failure.

Updates will be provided for as long as the disposable reference is kept alive.

import com.phenixrts.common.Disposable;
import com.phenixrts.room.ImmutableRoom;

final ImmutableRoom room = ...  // previously obtained

final Disposable disposable = room.getObservableEstimatedSize().subscribe((change) -> {
  final Long currentEstimatedRoomSize = (Long) change;
  // E.g. update UI
});

Room Model

The following details technical specifications for the Room, Members, and Streams.

ImmutableRoom

Name	Signature	Returns	Description
getRoomId	()	String	The room ID
getObservableAlias	()	Observable(of String)	Observable of room alias
getObservableName	()	Observable(of String)	Observable of room name
getObservableDescription	()	Observable(of String)	Observable of room description
getObservableType	()	Observable(of RoomType)	Observable of room type
getObservableMembers	()	Observable(of Member[])	Observable of array of visible members in the room
getObservableBridgeId	()	Observable(of String)	Observable of room bridgeId
getObservablePin	()	Observable(of String)	Observable of room pin
getObservableEstimatedSize	()	Observable(of Long)	Observable of estimated room size. This is a cumulative count of all members in the room, including audience members

Room

Room extends ImmutableRoom

Name	Signature	Returns	Description
commitChanges	(Room.CommitCallback)	void	Attempts to update server room model with any changes made locally
reload	()	void	Reverts all local changes to the server room model

Room Types

Type	Description
RoomType.DIRECT_CHAT	One to one chat
RoomType.MULTI_PARTY_CHAT	Many to many or few to many chat
RoomType.MODERATED_CHAT	Moderated chat with integrated SIP Bridge for conferencing abilities (join by phone).
RoomType.TOWN_HALL	Chat with a few active participants or presenters and many audience or inactive participants
RoomType.CHANNEL	View only room with a single active member at a time. Broadcast content to many viewers.

Member

Name	Signature	Returns	Description
getSessionId	()	String	The session ID of the member in the room
getObservableRole	()	Observable(of MemberRole)	Observable of member role
getObservableState	()	Observable(of MemberState)	Observable of member state
getObservableScreenName	()	Observable(of String)	Observable of member screen name
getObservableStreams	()	Observable(of Stream[])	Observable of array of streams belonging to the member
getObservableLastUpdate	()	Observable(of Date)	Observable of utc timestamp
commitChanges	(Member.CommitCallback)	void	Attempts to update server member model with any changes made locally
reload	()	void	Reverts all local changes to the server member model

Member Roles

Role	Description
MemberRole.PARTICIPANT	Member with streams and is visible to all members
MemberRole.AUDIENCE	Member with no streams and is not visible to other members
MemberRole.PRESENTER	Presenter participant member
MemberRole.MODERATOR	Privileged participant member

Member States

Role	Description
MemberState.ACTIVE	Member is active
MemberState.PASSIVE	Member is not active
MemberState.HAND_RAISED	Member is requesting to become active
MemberState.INACTIVE	Member is not away
MemberState.OFFLINE	Member has left the room

Stream

The stream object may be used to represent any value that will be shared between all members.

Name	Signature	Returns	Description
getUri	()	String	The stream uri (may or may not be associated with phenix stream ID)
getType	()	StreamType	The stream type
getObservableAudioState	()	Observable(of TrackState)	Observable of stream video state
getObservableVideoState	()	Observable(of TrackState)	Observable of stream audio state

Stream Types

Type	Description
StreamType.USER	General purpose stream
StreamType.PRESENTATION	Privileged stream
StreamType.AUDIO	Audio-only stream

Stream Track States

State	Description
TrackState.ENABLED	Track is enabled
TrackState.DISABLED	Track is disabled
TrackState.ENDED	Track has ended

Chat Service

The Chat Service provides the ability to:

Send messages to a room
Receive messages from a room
Get a room’s chat message history

All room members that are subscribed to the chat will receive the text messages. You must first enter the room before you may send and receive messages.

Initializing

First, instantiate the chat service. A Room Service is required to obtain the chat service.

import android.content.Context;

import com.phenixrts.chat.RoomChatService;
import com.phenixrts.chat.RoomChatServiceFactory;
import com.phenixrts.environment.android.AndroidContext;
import com.phenixrts.room.RoomService;

// IMPORTANT: Before accessing any of the static factories, make sure the context is passed to Phenix:
final Context context = ...;  // e.g. Activity.getApplication();
AndroidContext.setContext(context);

final RoomService roomService = ...;  // previously obtained

final RoomChatService chatService = RoomChatServiceFactory.createRoomChatService(roomService);


// Use a custom batch size, i.e. max number of message returned by 'getObservableChatMessages'
final int batchSize = 10;
final RoomChatService chatServiceWithBatchSize = RoomChatServiceFactory.createRoomChatService(
    roomService, batchSize);

RoomChatService

Name	Signature	Returns	Description
getObservableChatMessages	()	Observable(of ChatMessage[])	Get the observable of the most recent chat messages. This is a buffer of the most recent N messages up to a max of 100. See Listen for Chat Messages
getObservableChatEnabled	()	Observable(of Boolean)	Get the observable of the enabled status of the chat service. Use this to disable or enable the chat.
sendMessageToRoom	(message, callback)	void	Send a message to room.
getMessages	(batchSize, afterMessageId, beforeMessageId, callback)	void	Get chat message history

ChatMessage

Name	Type	Description
getMessageId	String	Unique ID of message
getObservableTimeStamp	Observable(of Date)	Server UTC timestamp of message
getObservableFrom	Observable(of ChatUser)	Information on the member that sent the message
getObservableMessage	Observable(of String)	Chat message

ChatUser

Name	Type	Description
getSessionId	String	Member’s session ID
getObservableScreenName	Observable(of String)	Screen name of the member
getObservableMemberRole	Observable(of MemberRole)	Member’s role. See Member Roles
getObservableLastUpdate	Observable(of Date)	Last time member was updated as UTC timestamp

Listen for Chat Messages in the Active Room

The chat service exposes an observable of the most recent N (batchSize) messages in the active room up to a max of 100 messages. To view older messages you will need to use the getMessages method.

import com.phenixrts.common.Disposable;
import com.phenixrts.common.Observable;
import com.phenixrts.chat.ChatMessage;
import com.phenixrts.chat.RoomChatService;
import com.phenixrts.chat.RoomChatServiceFactory;
import com.phenixrts.room.RoomService;

final RoomService roomService = ...;  // previously obtained

final int batchSize = 10;
final RoomChatService chatService = RoomChatServiceFactory.createRoomChatService(roomService, batchSize);

final Observable<ChatMessage[]> chatMessageObservable = chatService.getObservableChatMessages();

final Disposable subscription = chatMessageObservable.subscribe((change) -> {
  final ChatMessage[] messages = (ChatMessage[])change;
  // Do something with chat messages
});

Send a Message to the Active Room

Send a single message to the active room. If the message is successfully sent the chatMessageObservable will trigger notifications on all subscribers with the new chat message.

import com.phenixrts.common.RequestStatus;
import com.phenixrts.chat.ChatMessage;
import com.phenixrts.chat.RoomChatService;

final RoomChatService chatService = ...;  // previously obtained

// Without callback:
chatService.sendMessageToRoom("My First Message");

// With callback
chatService.sendMessageToRoom("My First Message", (RequestStatus status, String message) -> {
  if (status == RequestStatus.OK) {
    // Successfully sent
  } else {
    // handle error - send message again
    // (`message` may provide more information about what went wrong)
  }
});

Parameters

Name	Type	Description
message (required)	String	Message to send to the room
sendMessageCallback (optional)	RoomChatService.SendMessageCallback	Callback with the status of the request

Send Message Callback Arguments

Name	Type	Description
status	RequestStatus	The status of the operation
message	String	Optional additional error status in case of a failure

Send Message Callback Status Codes

Status	Description
ok	Send message succeeded
<varies>	Send message failed for other reasons

Chat Message History

Get messages older than the most recent N buffered in the chatMessageObservable.

Get the 10 most recent messages after a message:

import com.phenixrts.common.RequestStatus;
import com.phenixrts.chat.ChatMessage;
import com.phenixrts.chat.RoomChatService;

final RoomChatService chatService = ...;  // previously obtained

final int batchSize = 10;
final String afterMessageId = "MessageId1";
final String beforeMessageId = null;

chatService.getMessages(
    batchSize,
    afterMessageId,
    beforeMessageId,
    (RoomChatService chatService, ChatMessage[] messages, RequestStatus status) -> {
  if (status == RequestStatus.OK) {
    // Successfully got chat messages
  } else {
    // handle error - request messages again
  }
});

Get all messages between two messages:

import com.phenixrts.common.RequestStatus;
import com.phenixrts.chat.ChatMessage;
import com.phenixrts.chat.RoomChatService;

final RoomChatService chatService = ...;  // previously obtained

final int batchSize = 100;
final String afterMessageId = "MessageId1";
final String beforeMessageId = "MessageId2";

chatService.getMessages(
    batchSize,
    afterMessageId,
    beforeMessageId,
    (RoomChatService chatService, ChatMessage[] messages, RequestStatus status) -> {
  if (status == RequestStatus.OK) {
    // Successfully got chat messages
  } else {
    // handle error - request messages again
  }
});

Parameters

Name	Type	Description
batchSize (required)	int	Limit of messages to receive.
afterMessageId (optional)	String	The messageId to return after. The N messages after message with ID of afterMessageId but before beforeMessageId
beforeMessageId (optional)	String	The messageId to return before. The N messages before message with ID of beforeMessageId
callback (required)	RoomChatService.GetMessagesCallback	Callback with the status of the request

Get Messages Callback Arguments

Name	Type	Description
roomChatService	RoomChatService	The chat service making the callback
messages	ChatMessage[]	Array of chat messages matching search criteria
status	RequestStatus	The status of the operation

Get Messages Callback Status Codes

Status	Description
ok	Get messages succeeded
<varies>	Get messages failed for other reasons

Observable

Observe value changes. Similar to the ReactiveX Behavior Subject.

Important differences for Phenix SDK observables:

There is always an initial value (which can be null for some objects)
Only if observed value changes will subscribers get notified

Point 1 means that when subscribing, you will always get notified immediately with the current value. This is guaranteed atomic, meaning that you do not have to worry about missing any observable updates.

Observable

Name	Signature	Returns	Description
subscribe	(onChanged)	Disposable	See Subscribe to an Observable
getValue	()	varies	See Get Observable Value
setValue	(value)	void	See Set Observable Value

Receive a notification every time the observable value changes.

import com.phenixrts.common.Disposable;
import com.phenixrts.common.Observable;

Observable<String> observable = ...;  // previously obtained

Disposable subscription = observable.subscribe((change) -> {
  String newStringValue = (String)change;
  // Do something with newStringValue
});

// Closing subscription will cancel it:
subscription.dispose();

Parameters

Name	Type	Description
onChangedHandler (required)	Observable.OnChangedHandler	Handler to call when value changes

Disposable

Has no methods, but does inherit from JavaObject. This allows canceling of subscription by calling dispose.

Get Observable Value

Synchronous method allowing retrieval of currently set value. Thread safe.

import com.phenixrts.common.Observable;
import com.phenixrts.room.Member;
import com.phenixrts.room.MemberRole;

Observable<MemberRole> roleObservable = ...;  // previously obtained
MemberRole role = roleObservable.getValue();

Observable<Member[]> membersObservable = ...;  // previously obtained
Member[] members = membersObservable.getValue();

Set Observable Value

Change the observable value. This will trigger notifications on all subscribers.

import com.phenixrts.common.Observable;
import com.phenixrts.room.MemberRole;

Observable<MemberRole> roleObservable = ...;  // previously obtained
roleObservable.setValue(MemberRole.PRESENTER);

Android SDK - Low Level APIs

Android SDK

Initializing

Initialize Options

Stream Source Mapping

Connect and Authenticate

Parameters

Authentication Callback Status Codes

Disconnect

Get Local User Media

Parameters

Device Capability

Constraint Type

Facing Mode

Flash Mode

Device Location

Polar Pattern

Audio Echo Cancelation Mode

Updating Options

Enumerating Source Devices

Parameters

SourceDeviceInfo fields

Media Type

Source Device Type

Screencasting android 5.0 or later

Publish a Stream

Parameters

StreamEndedReason

Process Raw Frames

Frame Notification API

AndroidAudioFrame

AndroidVideoFrame

Limit Bitrate

Parameters

Subscribe to a Stream

Parameters

View a Stream

Renderer options

Properties

Aspect Ratio Mode

Hardware Accelerated Decoding Mode

Preview Local User Media

Muting and Unmuting of Audio

Taking a Screenshot

Data Quality Feedback

Data Quality Status for Publishers

Data Quality Status for Viewers

Handling Dimension Changes

Room Service

Initializing

Parameters

RoomService

Instantiate Self Member Model

Update Self Model

Update Self Callback Arguments

Set Self Streams

Parameters

Get Room Info

Parameters

Get Room Info Callback Arguments

Get Room Info Callback Status Codes

Create a Room

Parameters

Create Room Callback Arguments

Create Room Callback Status Codes

RoomOptionsBuilder

Join a Room

Parameters

Join Room Callback Arguments

Join Room Callback Status Codes

Subscribe to Room Member Streams

Update Room Model

Parameters

Update Room Callback Arguments

Update Room Callback Status Codes

Leave a Room

Parameters

Leave Room Callback Arguments

Update Room Callback Status Codes

Destroy a Room

Screencasting `android 5.0 or later`
